The SMB RF coaxial connector interface features shield/contact crimp/solder as an attachment method.
The snap-on coupling mechanism provides a fast and reliable connection for high packing density applications. These versatile connectors are available in various materials to provide a low-cost solution and can be used in internal devices and cable assemblies. Jaw-Dropper SMB coaxial connector series provides a minimum frequency of DC and a maximum frequency of 3 GHz. RoHS and REACH compliant.
FEATURES AND BENEFITS
Various plating options in nickel, gold, and tin lead
Quick connect/disconnect snap on mating reduces installation time
SMB PCB slide-on plug and jack allows board-to-board mounting with a low insertion force
Global Positioning System (GPS)
SMB CONNECTOR SPECIFICATIONS
SMB Connector Specifications – 50/75 Ohm
DC – 4 GHz (DC – 10 GHz on Extended Range Designs)
335 Volts RMS Continuous
Dielectric Withstanding Voltage
1000 VRMS Max
VSWR (Return Loss)
Note: These characteristics are typical and may not apply to all connectors.
