LC connectors are designed with the interface of flange mount which operates up to a maximum frequency of 1 GHz. LC connectors enable designers to make external connections on product enclosures, and can be used in a variety of other rack mount and panel mount applications.
This LC coaxial RF connector series is RoHS and REACH compliant.
FEATURES AND BENEFITS
- Operating Frequency of 1 GHz Max.
- Silver Plated Beryllium Copper Contact
- Contact plating
- General Purpose Test
- Rack and Panel Mount Applications
LC CONNECTOR SPECIFICATIONS
|LC Connectors Specifications – 50Ohm|
|Frequency Range||DC – 1 GHz|
|Voltage Rating||5000 Volts RMS Continuous|
|Dielectric Withstanding Voltage||5000 VRMS Max|
|VSWR (Return Loss)|
|DC – 11 GHz|
|Center Contact Resistance|
|Outer Contact Resistance|
Note: These characteristics are typical and may not apply to all connectors.
