SMB CONNECTORS

The SMB RF coaxial connector interface features shield/contact crimp/solder as an attachment method.
The snap-on coupling mechanism provides a fast and reliable connection for high packing density applications. These versatile connectors are available in various materials to provide a low-cost solution and can be used in internal devices and cable assemblies. Jaw-Dropper SMB coaxial connector series provides a minimum frequency of DC and a maximum frequency of 3 GHz. RoHS and REACH compliant.

FEATURES AND BENEFITS

• Various plating options in nickel, gold, and tin lead
• Quick connect/disconnect snap on mating reduces installation time
• SMB PCB slide-on plug and jack allows board-to-board mounting with a low insertion force

APPLICATIONS

• Base Stations
• Antennas
• Radio Boards
• PC/LAN
• Global Positioning System (GPS)
• Instrumentation
• Telecommunications

SMB CONNECTOR SPECIFICATIONS

Note: These characteristics are typical and may not apply to all connectors.
